VIPER 13DL HYBRID CARAVAN

DESCRIPTION

The Viper 13DL is a compact, off-road family hybrid caravan. With spacious double bunks and a generous king size bed, the Viper 13DL also includes an ensuite shower & toilet, reverse cycle air conditioning, diesel heater, and lounge seating. Powered by a Redarc Manager30 battery management system, 400amp lithium battery, 2000W Redarc inverter, 500W of solar, and 240L fresh water means camping off-grid in the Viper 13DL will be a breeze.


Specifications:
Measurements
- Length (closed):6300mm
- Length (open):7200mm
- Width:2170mm
- Height:2650mm
- Ball Weight:233kg†
- Tare:2319kg†
- GTM:2767kg†
- ATM:3000kg†
- Sleeping Capacity:4


Exterior
- Chassis:Triple Hot Dipped Galvanised 6” Chassis
- Brakes:12″ Electric Brakes
- Underbody:Anti-Chip Protection
- Wheel Arch Flairs:Included
- ADR Compliant Safety Chains:2
- Gas Shock Absorbers:4
- Full Size Spare Wheel:2
- Tool Box:Two Door. Front Mounted. Alloy
- Jerry Can Holders:In Front Mounted Box with 4x Tie Down Points
- Awning:Electric, 3.5m(W)
- Annex:16oz Canvas Walls and Vinyl Floor
- Trailer Breakaway System:Included
- Rubber Seals:Automotive Grade Pinch Weld
- Suspension:Adjustable Independent Trailing Arm Coil Spring
- Tyres:265/75/R16 Off Road
- Wheels:6 Stud 16″ Alloy
- 9kg Gas Bottle Holder:2 In Front Mounted Box, adjustable to suit 4kg
- Stabilizer Legs:4x Drop-Down Heavy-Duty
- Fan in Fridge Slide:Included
- Bike Rack Receiver:On Rear Bar
- Rear View Camera:Yes


Camping Comforts
- Front Water Tank:120L Poly with Bash Plate
- Rear Water Tank:120L Poly with Bash Plate
- Grey Water Tank:80L Poly
- Kitchen & Drying Rack:Stainless Steel
- Fold-Over Prep Bench:Stainless Steel
- Gas Plumbing:To external Gas Bayonet (for Outdoor Kitchen)
- Plumbed Water:To Ensuite, Outdoor Kitchen and Drawbar Tap
- Temperature Control:Dometic Reverse-Cycle Air Conditioning. Diesel Heater with Digital Display. 4x Ranger 12V Cabin Fans
- Seating:Leatherette
- Flooring:Premium Vinyl
- Mattress:1x King Plush Inner Spring, 1x Double (1000mm (W)) and 1x Single (800mm (W)) High Density Foam
- TV:24″
- Entertainment System:DVD/CD/BT/Radio with 4 Speakers
- Ensuite:Dometic Cassette Toilet, Basin and Shower with dividing curtain
- External Shower:Yes, with privacy tent
- Clothesline:Removable, positioned on Drawbar


Storage
- Front Toolbox:Alloy, with Tie Down Points
- External:Lockable Slide Storage Compartments. Rear Pole Box. Lift Up and Slide Drawer Pantry
- Internal:Cupboards, Bedside Compartments and Under Seat Storage
- Automatic Sensor LED Light:Front Toolbox, Pantry and Fridge Slide
- Fridge Slide Dimensions:TBC
- Generator Slide Dimensions:TBC


Electrical
- Battery:Lithium Battery 400AH
- Battery Management:REDARC Manager30 with RedVision Monitor
- Inverter:REDARC RS3 Pure Sine Wave 2000W Inverter
- Solar Panels:500 Watt Roof Mounted
- Control Panel:Internal, with gauges and switches
- Gauges:2x Water Tank Level and 1x Grey Water Tank Level
- Fridge Slide:Anderson Plug, 12V Socket and 240V
- Internal:12V Sockets and 12V USB Sockets
- External:2x 3.5mm 12V Sockets
- External Kitchen:12V Sockets
- Courtesy Light:Ensuite
- Kitchen Light:LED
- Exterior Light:Dual Colour LED
- 240V Power System:15 Amp Inlet and 10 Amp Outlet
